Brand Name :	Original
Model Number :	TS321QDBVRQ1
Certification :	ISO9001:2015standard
Price :	please contact us
Payment Terms :	L/C, D/A, D/P, T/T, Western Union,paypal
Supply Ability :	10000pcs/months
Delivery Time :	1-3workdays

Add to Cart

TS321QDBVRQ1 Operational Amplifiers Amps Semiconductors SI8233BB-D-IS FDN338P

The marketing status values are defined as follows: ACTIVE: Product device recommended for new designs.

LIFEBUY:TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.

NRND: Not recommended for new designs.

Device is in production to support existing customers, but TI does not recommend using this part in a new design.

PREVIEW: Device has been announced but is not in production. Samples may or may not be available.

OBSOLETE: TI has discontinued the production of the device.

Product Attribute	Attribute Value
Product Category:	Operational Amplifiers - Op Amps
Mounting Style:	SMD/SMT
Package / Case:	SOT-23-5
Number of Channels:	1 Channel
Supply Voltage - Max:	30 V
GBP - Gain Bandwidth Product:	800 kHz
Output Current per Channel:	40 mA
SR - Slew Rate:	400 mV/us
Vos - Input Offset Voltage:	4 mV
Supply Voltage - Min:	3 V
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 125 C
Ib - Input Bias Current:	150 nA
Operating Supply Current:	600 uA
Shutdown:	No Shutdown
CMRR - Common Mode Rejection Ratio:	85 dB
en - Input Voltage Noise Density:	50 nV/sqrt Hz
Series:	TS321-Q1
Qualification:	AEC-Q100
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Amplifier Type:	Low Power Amplifier
Dual Supply Voltage:	+/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V
Features:	High Cload Drive
Height:	1.15 mm
Input Type:	Rail-to-Rail
Length:	2.9 mm
Maximum Dual Supply Voltage:	+/- 15 V
Minimum Dual Supply Voltage:	+/- 1.5 V
Operating Supply Voltage:	3 V to 30 V, +/- 1.5 V to +/- 15 V
Product:	Operational Amplifiers
Product Type:	Op Amps - Operational Amplifiers
	3000
Subcategory:	Amplifier ICs
Supply Type:	Single, Dual
Technology:	Bipolar
Voltage Gain dB:	100 dB
Width:	1.6 mm
Unit Weight:	0.000222 oz
