PCA9534ARGVR Moisture Sensitive 8 I/O Expanders 2.3 V to 5.5 V
Voltage - 40 C~+ 85 C
Number of I/Os: | 8 I/O |
Maximum Clock Frequency: | 400 kHz |
Supply Voltage - Max: | 5.5 V |
Supply Voltage - Min: | 2.3 V |
Minimum Operating Temperature: | - 40 C |
Maximum Operating Temperature: | + 85 C |
Mounting Style: | SMD/SMT |
Package / Case: | VQFN-16 |
Packaging: | Reel |
Packaging: | Cut Tape |
Packaging: | MouseReel |
Brand: | Texas Instruments |
Features: | Configuration Registers, Interrupt Pin |
Logic Family: | PCA9534A |
Moisture Sensitive: | Yes |
Operating Supply Voltage: | 2.3 V to 5.5 V |
Product: | I/O Expanders |
Product Type: | I/O Expanders |
Series: | PCA9534A |
Factory Pack Quantity: | 2500 |
Subcategory: | Interface ICs |
Type: | I/O Expander |
Unit Weight: | 0.001312 oz |
Features
• Low standby current consumption of 1 μA max
• I2C to Parallel port expander
• Open-drain active-low interrupt output
• Operating power-supply voltage range of 2.3 V to 5.5 V
• 5-V Tolerant I/O ports
• 400-kHz Fast I2C bus
• Three hardware address pins allow up to eight devices on the
I2C/SMBus
• Allows up to 16 devices on the I2C/SMBus when used in conjunction
with the PCA9534
See Section 5 for I2C Expander offerings
• Input and output configuration register
• Polarity inversion register
• Internal power-on reset
• Power-up with all channels configured as Inputs
• No glitch on power-up
• Noise filter on SCL and SDA inputs
• Latched outputs with high-current drive maximum
capability for directly driving LEDs
• Latch-up performance exceeds 100 mA Per JESD 78, Class II
• ESD protection exceeds JESD 22
– 2000-V Human-body Model (A114-A)
– 200-V Machine Model (A115-A)
– 1000-V Charged-device model (C101)
