PS2811-1-F3-A Transistor Output Optocouplers Opto-electronics

DESCRIPTION
The PS2811-1 and PS2811-4 are optically coupled isolators containing a GaAs light emitting diode and an
NPN silicon phototransistor in a plastic SSOP for high density applications.
The package is a Shrink SOP (Small Outline Package) type for high density mounting applications.

FEATURES
High current transfer ratio (CTR = 200% TYP. @ IF = 1 mA)
High isolation voltage (BV = 2 500 Vr.m.s.)
Small and thin package (4, 16-pin SSOP, Pin pitch 1.27 mm)
Ordering number of taping product: PS2811-1-F3: 3 500 pcs/reel : PS2811-4-F3: 2 500 pcs/reel
Pb-Free product
Safety standards
UL approved: UL1577, Single protection
CSA approved: CAN/CSA-C22.2 No. 62368-1, Basic insulation
VDE approved: DIN EN 60747-5-5 (Option)

APPLICATIONS
Programmable logic controllers
Small power supply
Hybrid IC
Modem/FAX
