JM38510/11405BGA Operational Amplifiers - Op Amps PM156AJ6/38510 IC

GENERAL DESCRIPTION
This data sheet covers the electrical requirements for a mono-lithic, low-power, internally-compensated JFET-input opera-tional amplifier as

specified in MIL-M-38510/114 for device types 01 to 06. Devices supplied to this data sheet are manufac-tured and tested at PMI's MIL M-38510 certified facility and are listed in QPL-38510.

Complete device requirements will be found in MIL-M-38510 and MIL-M-38510/1 14 for Class B and Class S processed de-vices.

GENERIC CROSS-REFERENCE INFORMATION
This cross-reference information is presented for the convience of the user. The generic-industry types listed may not have iden-tical operational performance characteristics across the military temperature range or reliability factors equivalent to the MIL-M38510 device.

ABSOLUTE MAXIMUM RATINGS
Supply Voltage Range................土22V
Input Voltage Range (Note 1) ................. 土20V
Differential Input Voltage Range ................ 土40V
Lead Temperature (Soldering, 60 sec) .......... 300° C
Junction Temperature ............ T_j= 175°C (Note 3)
Storage Temperature Range ......... -65°C to + 150°C
Output Short-Circuit Duration ...... Unlimited (Note 2)
