SLVU2.8-4BTG ESD Suppressors / TVS Diodes 2.8V 1uA 4CH 30kV ESD Contact

Features

• ESD, IEC 61000-4-2, ±30kV contact, ±30kV air

• EFT, IEC 61000-4-4, 40A (5/50ns)

• Lightning, IEC 61000-4-5 2nd edition, 40A (8/20μs)

• Low capacitance of 2pF per line

• Low leakage current of 1μA (MAX) at 2.8V

• SOIC-8 (JEDEC MO-012) pin configuration allows for simple flow-through layout

• RoHS Compliant and Lead Free

• Moisture Sensitivity Level (MSL-1)

Description

Features Applications The SLVU2.8-4 was designed to protect low voltage, CMOS devices from ESD and lightning induced transients. There is a compensating diode in series with each low voltage TVS to present a low loading capacitance to the line being protected. These robust structures can safely absorb repetitive ESD strikes at ±30kV (contact discharge) per IEC 61000-4-2 standard and each structure can safely dissipate up to 40A (IEC 61000-4-5 2nd edition, tP=8/20μs) with very low clamping voltages.
