1 Features
• Industry-Standard Pin Out
• Two Independent Gate-Drive Channels
• 5-A Peak Source and Sink-Drive Current
• Independent-Enable Function for Each Output
• TTL and CMOS Compatible Logic Threshold Independent of Supply
Voltage
• Hysteretic-Logic Thresholds for High Noise Immunity
• Ability to Handle Negative Voltages (–5 V) at Inputs
• Inputs and Enable Pin-Voltage Levels Not Restricted by VDD Pin
Bias Supply Voltage
• 4.5 to 18-V Single-Supply Range
• Outputs Held Low During VDD-UVLO (Ensures Glitch-Free Operation
at Power Up and Power Down)
• Fast Propagation Delays (13-ns Typical)
• Fast Rise and Fall Times (7-ns and 6-ns Typical)
• 1-ns Typical Delay Matching Between 2-Channels
• Two Outputs are Paralleled for Higher Drive Current
• Outputs Held in Low When Inputs Floating
• SOIC-8, HVSSOP-8 PowerPAD™ Package Options
• Operating Temperature Range of –40 to 140°C
2 Applications
• Switch-Mode Power Supplies Dual Non-Inverting Inputs
• DC-to-DC Converters
• Motor Control, Solar Power
• Gate Drive for Emerging Wide Band-Gap Power Devices Such as GaN
Product Category: Gate Drivers Product: IGBT, MOSFET Gate Drivers Type: Low-Side Mounting Style: SMD/SMT Package / Case: SOIC-8 Number of Drivers: 2 Driver Number of Outputs: 2 Output Output Current: 5 A Supply Voltage - Min: 4.5 V Supply Voltage - Max: 18 V Configuration: Non-Inverting Rise Time: 7 ns Fall Time: 7 ns Minimum Operating Temperature: - 40 C Maximum Operating Temperature: + 140 C Series:
UCC27524A Packaging: Reel Packaging: Cut Tape Features: Enable Pin Operating Supply Current: 110 uA Operating Supply Voltage: 4.5 V to 18 V Product Type: Gate Drivers Factory Pack Quantity: 2500 Subcategory: PMIC - Power Management ICs Technology: Si Unit Weight: 0.002677 oz
