CD4066BM Switch ICs Analog Switch ICs SMD/SMT SMD/SMT 4 Channel

.15-V Digital or ±7.5-V Peak-to-Peak Switching

• 125-Ω Typical On-State Resistance for 15-V Operation

• Switch On-State Resistance Matched to Within 5 Ω Over 15-V Signal-Input Range

• On-State Resistance Flat Over Full Peak-to-Peak Signal Range

• High On or Off Output-Voltage Ratio: 80 dB Typical at fis = 10 kHz, RL = 1 kΩ

• High Degree of Linearity: <0.5% Distortion Typical at fis = 1 kHz, Vis = 5-Vp-p VDD – VSS ≥ 10-V, RL = 10 kΩ

• Extremely Low Off-State Switch Leakage, Resulting in Very Low Offset Current and High Effective Off-State Resistance: 10 pA Typical at VDD – VSS = 10-V, TA = 25°C

• Extremely High Control Input Impedance (Control Circuit Isolated From Signal Circuit): 1012 Ω Typical

• Low Crosstalk Between Switches: –50 dB Typical at fis = 8 MHz, RL = 1 kΩ

• Matched Control-Input to Signal-Output Capacitance: Reduces Output Signal Transients

• Frequency Response, Switch On = 40 MHz Typical

• 100% Tested for Quiescent Current at 20-V • 5-V, 10-V, and 15-V Parametric Ratinga
